Qty. |
GFI |
|
| Item |
Req’d |
Number |
Description of Part |
| 1 |
1 |
7410 |
D114 Duct, Supply |
| 2 |
1 |
7411 |
VB14 Panel, Blower Supply W/insulation |
| 3 |
1 |
7412 |
BM14 Base, Motor |
| 4 |
1 |
7413 |
MT14 Motor - 115v, 1/10 Hp, 3 Spd |
| 5 |
1 |
7414 |
BW14 Blower Set (Wheel, Housing & inlet) |
| 6 |
1 |
7415 |
RC14 Capacitor, (Motor) |
| 7 |
1 |
7416 |
DP14 Drain Pan (Stainless) |
| 8 |
1 |
7417 |
SM14 Panel Side W/ Insulation |
| 9 |
1 |
7418 |
CO14 Coil |
| 10 |
1 |
7419 |
FT14 Filter, 431x 595 X 5 Mm, Nylon |
| 11 |
1 |
7420 |
UF14 Upper Groove, Filter |
| 12 |
1 |
7421 |
DR14 Duct, Return |
| 13 |
1 |
7422 |
TR14 Transformer, 115-24vac, 24va |
| 14 |
1 |
7423 |
VR14 Panel, Return Air W/ Insulation |
| 15 |
1 |
7424 |
LF14 Lower Groove Filter |
| 16 |
1 |
7425 |
SR14 Support, Side Panel Return Air |
| 17 |
1 |
7426 |
TX14 Tex Valve |
| 18 |
1 |
7427 |
FD14 Filter Drier |
| 19 |
1 |
7428 |
CS14 Compressor |
| 20 |
1 |
7429 |
BT14 Bottom Pan |
| 21 |
1 |
7430 |
SD14 Panel, Side W/ Insulation |
| 22 |
2 |
7431 |
SP14 Panel, Filter W/ Insulation |
| 23 |
1 |
7432 |
PP14 Pcb, Main |
| 24 |
1 |
7433 |
HC14 Sensor Module, Humidity W/harness |
| 25 |
1 |
7434 |
NC14 Knob, Control |
| 26 |
4 |
7435 |
RI14 Isolator, Rubber |
| 27 |
4 |
7436 |
AF14 Foot, Rubber, Adjustable |
| 28 |
1 |
7437 |
DS14 Switch, Door |
| 29 |
1 |
7438 |
CT14 Panel, Control |
| 30,31 |
1 |
7439 |
MH14 Grommet, Rubber, Closed, 7/8" OD |
| 32 |
1 |
7440 |
RH14 Pot, Rh Adjustment, W/ Harness |
| 33 |
1 |
7441 |
TP14 Panel, Top W/ Insulation |
| 35 |
1 |
7443 |
TS14 Terminal Strip, Tb-10, 5 Amp |
| 36 |
1 |
7444 |
TS14-1 Terminal Strip, Tb-6, 30 Amp |
| 37 |
1 |
7445 |
RC14-1 Capacitor, (Compressor) |
| 38 |
1 |
7446 |
DF14 Defrost Sensor W/ Harness |
